Glory Series LED Linear Lights
Suspended linear luminaires for offices, meeting rooms, retail and commercial interiors. 2835 SMD on aluminium PCB, single / double / triple row layouts, UGR≤16/19/20 optics, and lengths built to your ceiling in multiples of the lens module.
16/19/20Glare ratings
2.2 mStandard lengths
80 WPower options
Series Overview
Five Glory Series profiles cover single-row, double-row and triple-row layouts, with beam angles from narrow 24° to wide 160° and three glare classes. All share the same construction: anodised 6063 aluminium body, zinc-alloy die-cast end caps, 2835 SMD on aluminium PCB, and a UV-resistant optical PC lens available in many styles.
Body material
Anodised 6063 aluminium profile — higher heat dissipation efficiency; FEA-optimised thermal structure for longer lifespan.
Light source
2835 SMD on aluminium PCB. Flicker-free; isolated or non-isolated power supply types.
Optics
UV-resistant optical PC lens, multiple styles: single row, double row, triple row; micro-prismatic and clear options.
Mounting
Suspension installation with steel wires and suspension kits; installation completed in minutes.
Colours: black, white or silver body. Custom length: increased in multiples of the single lens length. Anti-glare: flicker-free, eye-protection design delivering soft light.
Model Range & Key Specifications
Luminaire lengths: 1T = one lens module. All models drive at 40 / 60 / 80 W with isolated or non-isolated drivers.
| Model | Layout | Beam angles | UGR | Cross-section (W×H) | Lengths (T-group) | Typical application |
|---|---|---|---|---|---|---|
| BC601D | Single / double row | 60° / 90° / 120° / 30×90° / P20° / RI25° / 160° | ≤16 | 67.2 × 22.6 mm | 1T=600, 2T=1200, 3T=1800 mm | Office buildings, offices |
| BC276K / BC276K2 | Double row | 60° / 90° / P24° / RL24° | ≤19 | 62.7 × 23 mm | 2T=552, 4T=1104, 6T=1656 mm | Retail, housing, office |
| BC746D | Single / double row | 65° / 90° / 120° / 100×80° / P20° / RL25° / 160° | ≤16 | 67.2 × 24.3 mm | 1T=744.5, 2T=1489, 3T=2233.5 mm | Offices, commercial spaces |
| BC276K3P12 | Triple row | 60° / 75° | ≤18 | 71 × 24.6 mm | 2T=552, 4T=1104, 6T=1656 mm | High-output office areas |
| BC148K3P6 | Triple row | 45° | ≤16 | 75 × 29 mm | 4T=590.5, 8T=1181, 12T=1771.5 mm | Aisles, shelving lines |
PCB widths from 42.5 mm to 65 mm; LED counts scale with length (e.g. BC601D single row 112/210/312 pcs at 1T/2T/3T). Exact PCB layout and LED quantity per model are confirmed on the datasheet at enquiry.
Construction
- Suspension kits — steel wire, adjustable height.
- Zinc-alloy die-cast end caps — colour matched to the body.
- Anodised 6063 aluminium lamp body — black / white / silver.
- 2835 SMD on aluminium PCB — single or double row layouts.
- UV-resistant optical PC lens — available in many styles, single or double row.
Thermal & Optical Engineering
The body structure is optimised with advanced FEA thermal simulation — thermal conductivity, air flow and convection are modelled to achieve longer lifespan at the best cost-efficiency. Optical performance is documented per model: polar curves, beam angles (e.g. 60°, 90°, P20°, RI25°) and illuminance distribution maps are available in the datasheet pack.
Example — 80 W fixture: luminous flux 2500 lm, luminous efficiency 90 lm/W at 3 m mounting height; documented spot diameter and illuminance maps per beam angle.
Applications
Offices & meeting rooms
UGR≤16 options for screen-heavy workstations; continuous runs along desk lines.
Retail & showrooms
Double-row layouts over aisles and displays; silver or black body to match the interior.
Conference & boardrooms
Suspended centrepiece runs with anti-glare, flicker-free optics.
Education & public interiors
Eye-protection design and custom lengths to fit room modules exactly.
Ordering & Packaging
- Confirm model, row layout, beam angle, UGR class and lengths.
- Choose body colour (black / white / silver) and driver type (isolated / non-isolated).
- For custom runs: length is increased in multiples of the single lens module.
- Sample approval, then batch production with pre-shipment inspection.
Frequently Asked Questions
Can the linear lights be made to custom lengths?
Which glare ratings are available?
Do you supply them with or without the driver and LED board?
What body colours are available?
Need Glory Series pricing?
Send the model, lengths, quantities and destination market — we reply with a quotation and lead time.
